PTFE Wedge Mechanical Seals for Pumps

Basic Info

Brand: Enactus

Place Of Origin: China

Speed: ≤20m/s

Size: Customized Size

Brand Name: Enactus

Application: Our products are successfully used in different fields, such as Water treatment, Petroleum, Chemistry, refinery, pulp & paper, food, marine etc.

Pressure: ≤1.2mpa

Temperature: -50 °C~+220 °C

Additional Info

Packaging: 1.Tissue paper + Carton box 2.As per customer`s requirement

Transportation: Ocean,Land,Air,Express

Place of Origin: China

Supply Ability: 100000 Piece/Pieces per Month

HS Code: 8484200090

Port: shanghai,guangzhou,ningbo

Product Description

The wedge design of these seals allows for self-adjustment and compensation of axial movement, ensuring a reliable and effective seal even in high-pressure applications. The PTFE material provides a low coefficient of friction, reducing wear and extending the lifespan of the seal.PTFE Wedge Mechanical Seals are commonly used in various industries, including chemical processing, pharmaceuticals, food and beverage, and wastewater treatment. They are suitable for handling corrosive and abrasive fluids, as well as liquids containing solid particles.These seals are typically installed in centrifugal pumps, where they are placed between the pump shaft and the pump housing. The wedge shape of the seal allows for easy installation and removal, making maintenance and replacement hassle-free.mechanical seal types,mechanical seal for water pump.
Operating Conditions
Temperature:  -40ºC to +250 ºC
Pressure:        ≤2.5 MPa
Speed:           ≤15 m/S
Combined Materials
Stationary Ring : V1,Q1,Q2
Rotary Ring : B,A,Q1,Q2
Secondary Seat : T
Spring and Metal Parts:   F,G,M
Seat Types
Standard : C16
Alternative : C12,C21,C22

Applications :Strong corrosive fluids.
