Mechanical Seal Hilge Pump Seal 19mm,28mm

Basic Info

Brand: Enactus

Place Of Origin: China

Additional Info

Packaging: Carton,outer package as request

Transportation: Ocean,Land,Air,Express

Place of Origin: China

Supply Ability: 1000000 Piece/Pieces per Month

Port: shanghai,guangzhou,ningbo

Product Description

A mechanical seal is a device used to prevent leakage between two rotating parts, such as a pump shaft and pump housing. It consists of two primary components: a stationary part, known as the seal face, and a rotating part, known as the seal ring. These two parts are held together with springs and are designed to create a tight seal to prevent the escape of fluid.

Hilge Pump Seals are specifically designed for use in Hilge pumps, which are centrifugal pumps commonly used in the food, beverage, and pharmaceutical industries. These seals are engineered to meet the specific requirements of Hilge pumps and are made from high-quality materials to ensure durability and reliability.Hilge Pump Mechanical Seal,Hilge Pump Seal.

Operations Conditions:
Temperature:-40ºC to +250ºC
Pressure:≤1.2MPa
Speed:≤15m/s
Materials:
Stationary Ring:Silicon Carbide Reaction Bonded,Ceramic(Alumina),Silicon Carbide Sintered Pressureless
Rotary Ring:Antimony Impreg. Carbon Graphite,Resin Impregnated
Carbon Graphite(Furan),Silicon Carbide Reaction Bonded,Silicon Carbide Sintered
Pressureless
Secondary Seal:Pure PTFE
Spring and Metal Parts:Stainless Steel,Stainless Steel,Hastelloy C-4 Alloy
Seat Type:
Standard:JR16
Alternative:JRN,JRT21
Applications:Strong corrosive fluids
