Hilge Water Seal Pump Seal Mechanical Seal

Basic Info

Brand: Enactus

Place Of Origin: China

Additional Info

Packaging: Carton,outer package as request

Transportation: Ocean,Land,Air,Express

Place of Origin: China

Supply Ability: 1000000 Piece/Pieces per Month

Port: shanghai,guangzhou,ningbo

Product Description

Hilge Water Seal Pump Seal Mechanical Seal is a type of mechanical seal used in water pumps. It is designed to prevent leakage of water from the pump, ensuring efficient and reliable operation.The Hilge Water Seal Pump Seal Mechanical Seal is made up of several components, including a stationary seal face and a rotating seal face. These faces are made of materials that can withstand the harsh conditions of water pumping, such as stainless steel or ceramic.The seal faces are pressed together with a spring or other mechanism, creating a tight seal that prevents water from escaping. This design also allows for some movement between the seal faces, accommodating for any misalignment or vibration that may occur during operation.In addition to the seal faces, the Hilge Water Seal Pump Seal Mechanical Seal also includes other components such as O-rings, gaskets, and a housing. These components work together to create a complete seal that can withstand the pressure and temperature of the water being pumped.Hilge Pump Mechanical Seal,Pusher Seals.

Materials:

Stationary Ring： RBSIC/99.5%,A12O3/SSiC

Rotary Ring：Antimony Impreg.Carbon Graphit/Resin Impregnated Carbon Graphite(Furan)/ SSiC/RBSIC/M106,M108

Secondary Seal：Resin Impregnated Carbon Graphite(Furan)/ EPR/Kalrez,Chemraz/CR/NBR/MVQ/FPM/Hast.C4

Shaft size：30mm, 35mm

Spring & Metal Parts：304/316 Stainless Steel/Hast.C4

Shaft Seals – Choose the One to Suit You

A wide range of shaft seal options is available to suit different media and applications.

The single inboard seals maintain the optimum position in the liquid. This ensures efficient cleaning, lubrication and cooling.

Design:

O-ring Mechanical Seals
Rubber mechanical seals
Multi-Spring Mechanical seals

Seat ring:
Carbon Carbide and Silicon Carbide
