Sand Mill Mechanical Seal,Bead Mill Mechanical Seal

Basic Info

Brand: Enactus

Place Of Origin: China

Size: Customized Size

Brand Name: Enactus

Temperature: -20 ~ 180ºC

Speed: up to 20m/S

Application: Slurry Pump Desulfurization Pump

Pressure: < 4Mpa

Additional Info

Packaging: Carton,outer package as request

Transportation: Ocean,Land,Air,Express

Place of Origin: China

Supply Ability: 100000 Piece/Pieces per Month

HS Code: 8484200090

Port: shanghai,guangzhou,ningbo

Product Description

A sand mill mechanical seal is a device used to prevent leakage of the material being processed in a sand mill. It is typically used in industries such as paint, ink, and coating manufacturing. The mechanical seal is designed to withstand the high pressure and abrasive nature of the material being processed, ensuring that it does not leak out of the sand mill.
Similarly, a bead mill mechanical seal is used in bead mills, which are used for grinding and dispersing solid materials in a liquid medium. The mechanical seal in a bead mill is designed to prevent leakage of the material being processed, ensuring that it stays within the mill and does not contaminate the surrounding environment.

Both sand mill and bead mill Mechanical Seals are crucial components in their respective machines, as they help maintain the integrity of the process and prevent loss of valuable materials. They are typically made from materials that can withstand the harsh conditions of the milling process, such as stainless steel or ceramic, and are designed to provide a tight seal to prevent leakage.Sanding Machine Seal,Single Cartridge Seals.

Model Explaination:
Independent of direction of rotation
No damage of shaft by dynamically loaded O-ring
Extended service life
Material Combination:
Rotating ring: Tungsten carbide
Stationary ring: Tungsten carbide
Spring: 316L
Structure: 304SS,316L
Auxiliary seal: FFKM, PTFE,rubber O-ring
Operating Parameters:
Specification: 30~200 mm
Pressure: ≤ 0.5 MPa
Temperature: -20ºC~60ºC
Linear Velocity: ≤ 25 m/s
Axial Movement Value: ±0.5
Medium: oil,water,weak acid, other liquid
Features:
For plain shaft
Certificate: ISO9001
Adaptation to dimensions given by customer requirement
Good quality and competitive price
Applications:
Sand Mill and Bead Mill Chemical engineering
pharmacy, biochemistry, food, nano materials, paint, coating, adhesive, printing and
dyeing, petrochemical, pesticide, water treatment, photographic film, heavy oil emulsion and other industries.
